SKU: 105132

T4530 Bottom Bracket

Sale price€319,00
Finish: Standard
Color: Black
Standard
4
4 year warranty
Durable and serviceable design
Low friction
Coated
Lifetime warranty
Durable and serviceable design
Lowest friction
Exceptional corrosion resistance
ALPHA
RS 5-Spoke
RS ALPHA
RS ALPHA Team Edition
ADR
Notify me when available
Sale price€319,00
Aero ALPHA

Product description

Colnago created the ThreadFit82.5, aka ThreadFit, to make their oversized bottom brackets more durable. The T4530 bb threads into those 45mm diameter, 82.5mm wide shells and allows you to install 30mm diameter spindle cranks into your Colnago.

The cups have CeramicSpeed bearings pressed in, and then are threaded into the bb. There are two bearing options. The Standard Bearing has CeramicSpeed Balls and hardened-steel races. The Coated Bearing has the same balls running on a 3-micron thick coating placed on top of those hardened-steel races, which makes them faster and more durable.

In The Box

  • 2 cups with bearings installed.
  • 2 1mm spacers.
  • 2 0.5mm spacers.
  • 2 dust covers.
  • O-ring.
  • Spacer tube.
  • All Round Grease.
  • Sticker sheet.
Compatibility matrix
Discipline
Road, Tri, and Track
SKU
105132
Net weight
95.0 g
Gross Weight
177 g
BB Type
Threadfit 82.5 T45
Crank Diameter
30.0
Crank Brand
SRAM, Easton, FSA, Rotor, Cannondale, and Race Face

Lowest Friction

Optimized Power Transfer

Longest Product Lifetime

Drag

General Maintenance for CeramicSpeed Bottom Bracket and Wheel Bearings

Overview for how to clean and maintain CeramicSpeed Bearings used in Bottom Brackets and Wheel Hubs.

It is always important to follow these instructions and apply the proper maintenance to your CeramicSpeed Bottom Brackets and Bearings in order to achieve the lowest friction and the best longevity.

Installation of Shimano cranks on CeramicSpeed Bottom Brackets

CeramicSpeed Threaded Bottom Bracket installation guide

An overview for installing threaded CeramicSpeed Bottom Brackets including BSA, ITA, T47, and Colnago TF82.6/T45
